7CX-3 Trailer for Agricultural Use – Compatible with Moldboard Plow, Light Rake & Medium Harrow
Product Name: 7CX-3 Agricultural Farm Trailer
Suitable For: Transporting crops, fertilizers, feed, livestock, equipment, and general farm materials; field harvesting support; farm maintenance operations.
Product Overview
The 7CX-3 Agricultural Farm Trailer is a robust and reliable transport solution designed specifically for farming operations. As an essential implement on any farm, this trailer provides the capacity and durability needed to move crops, supplies, equipment, and materials efficiently around the farm or between fields.
Engineered for towing by tractors in the 12-25 horsepower range, the 7CX-3 is perfectly matched to compact and utility tractors commonly found on small to medium-sized farms. With a generous loading capacity of 3 tons (3000 kg) and a spacious 3000x1600mm cargo bed, this trailer offers excellent hauling capability while remaining manageable for smaller tractors. At 680kg tare weight, it is robustly constructed yet light enough to maximize payload.
Key Technical Specifications
| Feature | Specification |
|---|---|
| Model | 7CX-3 |
| Cargo Box Dimensions (车厢尺寸) | 3000 mm x 1600 mm x 400 mm (L×W×H) |
| Overall Dimensions (外型尺寸) | 4200 mm x 1700 mm x 1800 mm (L×W×H) |
| Load Capacity (载重) | 3 tons (3000 kg / 6614 lbs) |
| Tare Weight (自重) | 680 kg (1499 lbs) |
| Tires / Quantity (轮胎/数量) | 750-16 / 2 tires |
| Brake System (刹车形式) | Air Brakes (Pneumatic) |
| Required Tractor Power (配套动力) | 12 – 25 hp |
Detailed Features and Benefits
1. Spacious Cargo Area
The 7CX-3 features a large cargo box measuring 3000mm in length, 1600mm in width, and 400mm in depth (approximately 10ft x 5.2ft x 1.3ft).
-
Volume: This generous size provides ample space for transporting bulk crops, hay bales, bags of fertilizer, livestock feed, or farm equipment.
-
Versatility: The open-top design allows for easy loading from all sides, whether by hand, with a front-end loader, or using conveyor systems.
-
Low Sides: The 400mm side height strikes a balance between retaining loose materials and allowing easy access for loading and unloading.
2. 3-Ton Payload Capacity
With a rated load capacity of 3 tons (3000 kg) , the 7CX-3 is a true workhorse for small to medium farms:
-
Harvest Support: Haul significant quantities of grain, vegetables, fruit, or forage from field to storage.
-
Supply Transport: Move multiple tons of fertilizer, seed, or animal feed in a single trip, saving time and fuel.
-
General Utility: Transport tools, fencing materials, building supplies, and other farm essentials with ease.
3. Heavy-Duty Construction (680kg Tare Weight)
Weighing 680 kg empty, the 7CX-3 is built to last:
-
Durable Frame: Constructed from heavy-duty steel with reinforced chassis members to withstand the stresses of loaded farm transport over rough terrain.
-
Quality Materials: Built to resist corrosion and withstand the rigors of daily farm use in all weather conditions.
-
Stability: The substantial tare weight provides stability when towing, especially when lightly loaded or traveling empty.
4. 750-16 Pneumatic Tires
The trailer is equipped with two 750-16 tires:
-
Load Capacity: These heavy-duty tires are specifically selected to safely carry the 3-ton payload rating.
-
Flotation: The tire size provides good flotation in soft field conditions, reducing soil compaction and preventing the trailer from bogging down in wet areas.
-
Durability: Designed for agricultural use, these tires resist punctures and wear from field conditions.
5. Air Brake System (气刹)
The 7CX-3 features a pneumatic (air) brake system, a critical safety feature for loaded farm trailers:
-
Safety: Air brakes provide reliable, powerful stopping capability, especially important when the trailer is fully loaded to 3 tons.
-
Tractor Compatibility: Designed to connect to the tractor's air brake system, ensuring synchronized braking between tractor and trailer.
-
Control: Provides the operator with confident control on slopes, in traffic, or during emergency stops.
-
Compliance: Meets safety standards for agricultural trailers in many regions.
6. Wide Tractor Compatibility
Designed for tractors in the 12-25 horsepower range, the 7CX-3 is compatible with the compact and utility tractors commonly found on small farms. The towing hitch is adjustable to match different tractor drawbar heights, ensuring proper alignment and safe towing.
Ideal Applications
1. Crop Harvesting and Transport
During harvest season, the 7CX-3 becomes an indispensable tool for moving produce from field to storage or market. Whether hauling vegetables, fruit, grain, or forage, the 3-ton capacity means fewer trips and faster harvest completion.
2. Livestock Operations
For livestock farmers, this trailer is ideal for transporting feed bags, hay bales, bedding materials, and even small livestock. The sturdy construction and high sides (with optional extensions) make it suitable for various livestock hauling needs.
3. Fertilizer and Amendment Application
When spreading fertilizer, lime, or soil amendments, the 7CX-3 can be loaded in the barn and towed to the field, eliminating multiple trips with smaller containers.
4. General Farm Maintenance
From moving fencing posts and tools to hauling away debris, the 7CX-3 is the perfect companion for daily farm maintenance tasks. Its versatility makes it one of the most-used implements on the farm.
5. Orchard and Vineyard Work
In orchards and vineyards, the compact overall dimensions (4200mm length, 1700mm width) allow the trailer to maneuver between rows while still providing substantial carrying capacity for harvested fruit.
Conclusion
The 7CX-3 Agricultural Farm Trailer is a reliable, durable, and versatile transport solution for small to medium-sized farms. Perfectly matched to 12-25hp tractors, it offers a generous 3-ton payload capacity, a spacious 3000x1600mm cargo bed, and the safety of air brakes. At 680kg tare weight, it is robustly built yet maximizes payload efficiency. Whether for harvest support, supply transport, or daily farm tasks, the 7CX-3 delivers the performance and reliability that farmers demand.
