Disc Plow 1LY-625 – Heavy-Duty Agricultural Disc Plow for Tractors
Product Name: 1LY-625 Heavy-Duty Hydraulic Disc Plow
Suitable For: Large-scale primary tillage; virgin land reclamation; heavy clay soils; stony and root-laden fields; deep plowing in extreme conditions.
Product Overview
The 1LY-625 Disc Plow is a formidable agricultural implement engineered for the most demanding tillage operations. As the largest model in the 1LY series (based on the 625 designation), this plow is designed exclusively for high-horsepower tractors, requiring a robust 160 hp power source to operate at peak efficiency.
This implement represents the pinnacle of disc plow technology, combining a massive working width with deep penetration capabilities. Featuring six heavy-duty concave discs of 660mm diameter, the 1LY-625 is built to tackle the toughest field conditions imaginable—from hard, sun-baked clay soils to rocky ground and land thick with crop residues or roots.
With a substantial working width of 1500mm and a weight of 640kg, this plow delivers maximum productivity for large-scale farmers, custom tillage operators, and land reclamation projects. It is the tool of choice when speed, depth, and durability are non-negotiable requirements.
Key Technical Specifications
| Feature | Specification |
|---|---|
| Model | 1LY-625 |
| Structure Type | Category II Three-Point Linkage (Heavy-Duty) |
| Working Width (耕幅) | 1500 mm (1.5 Meters / 59 Inches) |
| Working Depth (耕深) | 250 – 300 mm (10 – 12 Inches) |
| Disc Diameter (犁片直径) | 660 mm (26 Inches) |
| Number of Discs (犁片数量) | 6 Discs |
| Machine Weight (重量) | 640 kg (1411 lbs) |
| Required Tractor Power | 160 hp (Minimum) |
| Mounting Type | Standard 3-Point Hitch (Category II) |
Detailed Features and Benefits
1. Category II Heavy-Duty Three-Point Linkage
The 1LY-625 is equipped with a reinforced Category II three-point hitch, designed to withstand the immense stresses generated during deep plowing with six discs. This heavy-duty linkage system ensures a secure and stable connection to high-horsepower tractors, typically in the 150-180 hp range. The robust construction of the hitch points and lift arms prevents flexing and ensures that the full power of the tractor is transferred efficiently to the soil-breaking action of the discs.
2. Massive Working Width for Maximum Productivity
With a working width of 1500mm (1.5 meters) , the 1LY-625 is a productivity powerhouse.
-
Efficiency: This width allows farmers to cover significantly more ground in less time compared to smaller plows. In a single pass, this implement can till a 1.5-meter-wide strip to a depth of 300mm, dramatically reducing fuel consumption and labor costs per hectare.
-
Field Completion: The wide span means fewer passes are required to complete a field, reducing soil compaction from tractor wheels and preserving soil structure for better crop establishment.
3. Deep Tillage Capability (250-300mm)
The ability to plow consistently to depths of 250-300mm is a defining feature of the 1LY-625. This deep tillage capability offers several agronomic benefits:
-
Hardpan Breaking: Regular shallow plowing can create a compacted layer (hardpan) just below the plowed depth. The 1LY-625 shatters this layer, improving drainage and root penetration.
-
Moisture Management: Deep plowing allows for better water infiltration and storage in the soil profile, making crops more resilient to drought conditions.
-
Residue Incorporation: The deep working depth ensures that heavy crop residues (such as maize stalks or sunflower stubble) are thoroughly buried, where they can decompose and contribute to soil organic matter.
4. Six 660mm Discs for Extreme Conditions
The heart of the 1LY-625 lies in its six large 660mm diameter concave discs. Each disc is engineered for maximum durability and performance:
-
Premium Materials: The discs are typically constructed from boron steel or other high-grade wear-resistant alloys. This material choice ensures that the discs maintain their sharpness and concave shape even after hundreds of hours of operation in abrasive soils.
-
Thickness and Strength: The disc thickness is optimized to resist bending or cracking when striking buried rocks, tree roots, or other obstacles. The "give" in the disc's rotation allows it to roll over obstacles rather than catching them like a traditional moldboard.
-
Gang Configuration: The six discs are arranged on one or more gangs, angled to ensure complete soil inversion and mixing. This configuration leaves a clean, well-broken furrow that is ready for weathering or secondary tillage.
5. Substantial Weight for Positive Penetration (640kg)
Weighing in at 640 kg, the 1LY-625 is a heavy implement by any standard. This weight serves a critical function:
-
Penetration Force: In hard, dry soils, implement weight is essential for forcing the discs into the ground. The 640kg mass, combined with the tractor's hydraulic downforce, ensures that the discs bite into even the most challenging surfaces.
-
Stability: The heavy frame dampens vibrations and shocks from uneven ground, providing a smoother ride for the tractor and more consistent plowing depth across the entire working width.
6. Hydraulic Angle Adjustment
The 1LY-625 features a powerful hydraulic system for adjusting the disc angle. This allows the operator to fine-tune the plow's performance without leaving the cab:
-
Aggressive Angle: For maximum soil inversion and burial of weeds and residue, the discs can be set to a sharper angle.
-
Reduced Angle: In extremely hard or stony conditions, reducing the angle lowers the draft requirement and allows the discs to ride over obstacles more easily.
Ideal Applications
1. Large-Scale Row Crop Farming
For farmers growing corn, soybeans, wheat, or cotton on hundreds or thousands of acres, the 1LY-625 is an essential primary tillage tool. It prepares a deep, clean seedbed that promotes vigorous root growth and high yields.
2. Land Reclamation and Virgin Ground
When bringing new land into production—whether it's overgrown pasture, scrubland, or previously uncultivated ground—the 1LY-625 excels. Its six discs can cut through roots and small brush, turning the virgin soil into productive farmland.
3. Heavy Clay and Difficult Soils
In regions with heavy clay soils that are difficult to work, the 1LY-625's weight and disc design provide the necessary power to slice and crumble the soil, improving its structure and workability.
4. Custom Tillage Operations
For contractors who provide plowing services to other farmers, the 1LY-625 offers the combination of speed, depth, and durability required to complete jobs efficiently and profitably. Its 1.5-meter width allows for rapid coverage, while its robust construction ensures minimal downtime.
Conclusion
The 1LY-625 Heavy-Duty Disc Plow is the ultimate tillage solution for farmers and contractors who demand maximum performance from their 160hp-class tractors. With its 1500mm working width, 300mm depth capability, and six 660mm discs, this 640kg implement is built to conquer the toughest fields and deliver unmatched productivity. For large-scale agriculture, land clearing, and deep soil management, the 1LY-625 stands as a testament to robust engineering and efficient design. It is not just a plow; it is a complete tillage system for the modern, high-production farm.
